Multi-point file backup, access and sync
HBS (Hybrid Backup Sync) consolidates data backup, recovery, and data synchronization. With high-speed 10GbE connectivity, you can easily back up or sync data to another QNAP NAS, remote server or cloud storage to build a reliable disaster recovery solution. Qsync turns the TS-832PXU-RP into a secure, high-capacity data center for file synchronization. Any file uploaded to the TS-832PXU-RP will be made available for all linked devices, such as computers, laptops, and mobile devices. You can also sync shared folders or create team folders to enhance team collaboration.
Learn More:HBS (Hybrid Backup Sync),Qsync cross-platform file sharing
|CPU||AnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 quad-core 1.7GHz processor|
|CPU Architecture||64-bit ARM|
|Floating Point Unit|
|System Memory||4 GB UDIMM DDR4 (1 x 4 GB)|
|Maximum Memory||16 GB (1 x 16 GB)|
|Memory Slot||1 x Long-DIMM DDR4|
|Flash Memory||512 MB (Dual boot OS protection)|
|Drive Bay||8 x 3.5-inch SATA 6Gb/s, 3Gb/s|
|Drive Compatibility||3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
|M.2 SSD Slot||Optional via a PCIe adapter|
|SSD Cache Acceleration Support|
|2.5 Gigabit Ethernet Port (2.5G/1G/100M)||2 (also support 10M)|
|10 Gigabit Ethernet Port||2 x 10GbE SFP+|
|Wake on LAN (WOL)||
Only the 2.5GbE port
Slot 1: PCIe Gen 2 x2
PCIe bandwidth limitations will restrict the NAS 10GbE performance.
|USB 3.2 Gen 1 port||4|
|Form Factor||2U Rackmount|
|LED Indicators||HDD 1-8, Status, LAN, Storage expansion|
|Dimensions (HxWxD)||89 × 482 × 534 mm|
|Weight (Net)||10.94 kg|
|Weight (Gross)||16.87 kg|
|Operating temperature||0 – 40 °C (32°F – 104°F)|
|Storage Temperature||-20 – 70°C (-4°F – 158°F)|
|Relative Humidity||5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)|
|Power Supply Unit||250W (x2) PSU, 100 – 240V|
|Power Consumption: Operating Mode, Typical||69.191 W
Tested with drives fully populated.
|Fan||2 x 70mm, 12VDC|
|Sound Level||30.6 db(A)|
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test
Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
