With its powerful AMD Ryzen™ V1000 series V1500B Quad-core processor, the TS-1273AU-RP is capable of boosting virtual machine performance with up to 4 cores/8 threads at 2.2GHz. The TS-1273AU-RP includes two 2.5GbE ports and two PCIe Gen 3 slots, providing you with fast network connectivity and the ability to add extra functionality and additional application potential. The TS-1273AU-RP also features a redundant power supply to ensure maximum system uptime. Cutting-edge hardware integrated with comprehensive software solutions makes the TS-1273AU-RP the preeminent choice to tackle resource-demanding applications and tasks.
Block-based iSCSI LUN: Ideal choice for virtualization storage
The TS-1273AU-RP supports block-based iSCSI LUN and is compatible for VMware®, Citrix®, Microsoft® Hyper-V®, and Windows Server® 2019 virtualization environments to provide a high-performance and affordable storage solution. The TS-1273AU-RP also supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi server and Hyper-V respectively, and supporting QNAP vSphere Client plug-in with enhanced operational efficiency and management in virtualization applications.
Optimized performance for VMware Virtualization with iSER
The iSCSI Extensions for RDMA (iSER) protocol boosts the data transfer performance of VMware® ESXi storage and reduces the CPU load of the ESXi server. iSER support can be added to the TS-1273AU-RP by installing a QNAP QXG-10G2SF-CX4 10GbE PCIe card, which uses the NVIDIA® Mellanox ConnectX-4 controller. iSER can provide a significant increase in performance, providing an essential tool to optimize demanding virtualization applications.
Note: To create an iSER connection with VMware ESXi, both the server and NAS require compatible NVIDIA® Mellanox NICs and switches compatible with NVIDIA® Mellanox or supporting PFC (Priority Flow Control) configuration.
|CPU||AMD Ryzen™ Embedded V1500B quad-core 2.2 GHz processor|
|CPU Architecture||64-bit x86|
|Floating Point Unit|
|Hardware-accelerated Transcoding||Optional via a PCIe graphics card|
|System Memory||8 GB UDIMM DDR4 (1 x 8 GB)|
|Maximum Memory||64 GB (2 x 32 GB)|
|Memory Slot||2 x Long-DIMM DDR4
Support ECC memory
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
|Flash Memory||5GB (Dual boot OS protection)|
|Drive Bay||12 x 3.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/
|Drive Compatibility||3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
|M.2 SSD Slot||Optional via a QNAP QM2 PCIe card|
|SSD Cache Acceleration Support|
|2.5 Gigabit Ethernet Port (2.5G/1G/100M)||2 (also support 10M)|
|5 Gigabit Ethernet Port (5G/2.5G/1G/100M)||Optional via a network adapter|
|10 Gigabit Ethernet Port||Optional via a network adapter|
|Wake on LAN (WOL)||
Only the 2.5GbE port
|PCIe Slot||2 x PCIe Gen3 x4|
|USB 3.2 Gen 1 port||1 x Type-A|
|USB 3.2 Gen 2 (10Gbps) Port||2 x Type-C
1 x Type-A
|HDMI Output||Optional via a PCIe graphics card|
|Form Factor||2U Rackmount|
|LED Indicators||HDD 1-12, Status, LAN, USB, Power|
|Dimensions (HxWxD)||89 × 482 × 425 mm|
|Weight (Net)||9.69 kg|
|Weight (Gross)||14.62 kg|
|Operating temperature||0 – 40 °C (32°F – 104°F)|
|Storage Temperature||-20 – 70°C (-4°F – 158°F)|
|Relative Humidity||5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)|
|Power Supply Unit||300W (x2) PSU, 100 – 240V|
|Power Consumption: HDD Sleep Mode||43.67 W|
|Power Consumption: Operating Mode, Typical||78.92 W
Tested fully populated with WD10EFRX hard drives.
|Fan||2 x 80mm, 12VDC|
|Sound Level||22.3~45.9 db(A)|
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test
Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
