The QSW-M2108-2S is a Layer 2 Web Managed Switch with two 10GbE SFP+ ports and eight 2.5 Gigabit ports. Supporting Layer 2 switching and network management via a user-friendly web user interface, the QSW-M2108-2S offers flexible deployment in hybrid high-speed network environments and provides an entry-level network management solution that is usable even by non-IT professionals. With high performance, user-friendly management, and desktop form factor, the QSW-M2108-2S enables cost-effective upgrading to 2.5GbE or 10GbE networking while optimizing bandwidth and ensuring secure network maintenance.
Flexible deployment with multiple 10G SFP+ fiber and Gigabit ports
The QSW-M2108-2S provides two 10GbE SFP+ ports and eight 2.5 Gigabit ports for connecting various devices and enabling hybrid high-speed networks. With SFP+ interfaces, Direct Attach Copper (DAC) cables can be used for connecting directly to SFP+ devices. You can also use RJ45 ports to connect 10GBASE-T/NBASE-T™ devices through RJ45 Category 6 (or better) cabling. The switching capacity of the QSW-M2108-2S is 80Gbps, guaranteeing the full potential of each port.
Note: 10GbE SFP+ ports are backward compatible with 1GbE SFP.
Desktop form factor for easy use in offices
With a compact and modern design, the QSW-M2108-2S stands out with its delicate textured surface design. The flexible DC power connector enables universal deployment of the QSW-M2108-2S and each port can be easily identified. Being fully plug-and-play, devices can be simply connected to the QSW-M2108-2S and immediately used.
|Management Type||Web Managed|
|Number of Ports||10|
|Management Port||1 x 1GbE RJ45|
|Power Supply Description||Adapter|
|Max. Power Consumption||12.17 W|
|Input Power Type||DC|
|Input Voltage Range||12V|
|MAC Address Table||16K|
|Total Non-Blocking Throughput||40Gbps|
|Energy Efficient Ethernet (IEEE 802.3az complaint)|
|Fan||PWM double ball bearing fan x 1|
|Supported Standards||IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-SX/LX
IEEE 802.3ae 10G Fiber
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.1Q VLAN Tagging
IEEE 802.1w RSTP
IEEE 802.3ad LACP
IEEE 802.1AB LLDP
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.1p Class of Service
|LED Indicators||Per Port: Speed/Link/Activity
Per System: Power/Status
|Dimensions (HxWxD)||42.5 x 290 x 127 mm|
|Weight (Net)||1.12 kg|
|Weight (Gross)||1.52 kg|
|Operating Temperature||0˚C to 40°C (32°F to 104°F)|
|Relative Humidity||5~95% Non-condensing|
|Certifications||CE, FCC, VCCI, BSMI|
|Electromagnetic Compliance||CLASS A|
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test
Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
