Type | Automatic Document Feeder (ADF) |
Image Sensor | CIS X 2 (Duplex) |
Light Source | LED |
Optical Resolution | 600 dpi |
Hardware Resolution | 600 x 600 dpi |
Scan Modes | Color: 48-bit input, 24-bit output |
Grayscale: 16-bit input, 8-bit output |
B/W: 1-bit |
ADF Capacity | 1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs) |
2. 30 sheets (Business Cards) |
3. Plastic Card, Max. thickness under 1.2 mm. |
Note: Maximum ADF capacity varies, depending upon paper weight. |
Scanning Speed ( ADF ) |
80 ppm/ 160 ipm (Grayscale/B&W mode, 200 dpi, A4 Portrait) |
80 ppm/ 160 ipm (Grayscale/B&W mode, 300 dpi, A4 Portrait) |
45 ppm/ 90 ipm (Color mode, 200 dpi, A4 Portrait) |
30 ppm/ 60 ipm (Color mode, 300 dpi, A4 Portrait) |
Note: Results may vary depending upon your scanning application, computer processor and system memory. |
Scan Area (L x W) | Maximum: 216 x 5080 mm (8.5 “x 200”) |
Minimum: 13.2 x 13.2 mm (0.52 “x 0.52”) |
Scan: Kartu Nama, A5, Kuarto, Letter, A4, Folio (F4), Legal |
Acceptable Paper Sizes (W x L) | Maximum: 216 x 5080 mm (8.5 “x 200”) |
Minimum: 50.8 x 50.8 mm (2 “x 2”) |
Acceptable Paper Weight (Thickness) | 40 to 220 g/㎡ (10 to 58 Lbs) |
Multi-feed Detection | With ultrasonic technology |
Daily Duty Scan ( Sheets ) | 8,000 |
Roller Lifetime (Scans) | 300,000 |
Pad Lifetime (Scans) | 100,000 |
Action Button | 4 Buttons: Up, Down, Scan, Standby |
9 function keys are all customizable. |
Power Supply | 24 Vdc/ 1.25 A |
Interface | USB 2.0 x 1, USB 2.0 (Host) x 1 |
Net Weight | 2.7 Kgs (5.95 Lbs) |
Dimensions (L x W x H) | 318.7 x 230.7 x 228.3 mm (12.55 “x 9.08” x 8.99 “) |
Protocol | TWAIN Compliant |
OS | Windows XP / Vista / 7 / 8 / 10 / 11 |
macOS 10.8.x/ 10.9.x/ 10.10.x/ 10.11.x/ 10.12.x/ 10.13.x/ 10.14.x/ 10.15.x/ 11.x/ 12.x/ 13.x/ 14.x |
Linux compatibility is only available for system integrators. Please contact [email protected] for more info. |
Hardware Requirements | Windows and Mac |
2.0 GHz CPU processor or higher[1][2][3] |
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher |
[2]Support Mac INTEL and M1 based processor |
[3]Compatibility is not available with PowerPC |
4 GB RAM minimum (Recommended: 8 GB or more) |
6 GB of hard-disk space for program installation |
Display dimensions of 1024×768 or greater |
Bundled Software | Plustek DocAction |
Plustek DocTWAIN |
Plustek MacAction |
Plustek ICA |
*Installation DVD only included software and driver for Windows. For Mac, please download from our website. |
Built-in OCR | Plustek OCR (For Windows)
(Powered by ABBYY® FineReader®) |
Plustek DocOCR (For Mac) |
*Installation DVD only included software and driver for Windows. For Mac, please download from our website. |
