Digitalsense

TS-473A-8G

5/5

Rp 17.900.000
sudah termasuk PPN 11%

Untuk Pemesanan Konfirmasi Terlebih Dahulu
● Processor : AMD RX-421ND 2.1~3.4 GHz, 8GB DDR4 RAM (max 64GB),
● Memory : 8x 2.5″/3.5″ + 2x M.2 2280/2260 SATA 6Gb/s slots
● Slot Bay : 4-Bay NAS

Anda dapat membeli di online store

SKU TS-473-8G Categories , , Tags , , , ,

Description

Greater NAS potential with two PCIe slots

The TS-473 features two PCIe (Gen3 x4) slots, allowing for installing single/dual-port 10GbE NICs to accelerate applications that demand higher bandwidth such as virtualization, media workflows, and backup/restoration tasks for an ever-growing amount of data; or a USB 3.1 Gen2 (10Gb/s) expansion card for transferring large media files to and from USB storage. You can also install QM2 cards, wireless network cards or an entry-level graphics card to extend NAS functionality.

Note: USB 3.1 performance may vary depending on hardware/software limitations and usage environment.


AMD R-Series quad-core CPU

Equipped with a next-gen AMD R-Series RX-421ND quad-core 2.1 GHz CPU (Turbo Core up to 3.4 GHz) with up to 64GB dual-channel DDR4 RAM, the TS-473 enables lightning-fast multi-tasking with low power consumption for up to 2347 MB/s throughput with a 10GbE configuration. With a hardware-accelerated AES-NI encryption engine, the TS-473 also provides unmatched encryption performance in its class (up to 2310 MB/s with AES 256-bit full NAS volume encryption) to boost system performance while ensuring the safety of sensitive business data stored on the NAS.




Top-class hardware engineering

The strong and feature-packed hardware bolsters overall system performance. Coupled with a flexible and expandable architecture, the TS-473 can fulfill diverse application needs.


SSD caching and 10GbE connectivity

The TS-473 supports the innovative QM2 PCIe card that allows for adding up to two M.2 SSDs. You can configure SSD caching, or create a RAID 5 tiered storage along with the two M.2 SSDs in the NAS*. As these M.2 SSDs will not occupy any 3.5-inch drive bays, the QM2 card allows you to maximize both your storage capacity and performance. There are also QM2 cards that include 10GbE 10GBASE-T connectivity to provide SSD caching with high-speed network connectivity on a single card.

*Note: M.2 SSDs for NAS and QM2 cards are sold separately.


SSD cache with Qtier™ optimization for around-the-clock acceleration

The TS-473 features SSD caching, and also supports optional M.2 SATA 6Gb/s SSDs (sold separately). Using an SSD cache boosts overall system performance, and is perfect for improving the overall workflow of random IOPS demanding applications such as virtualization. QNAP’s Qtier™ technology also continuously optimizes storage efficiency by tiering files and data across M.2 SSD, 2.5-inch SSD, and high-capacity SATA drives based on access frequency. The new Qtier™ 2.0 features IO-awareness that empowers SSD-tiered storage with a cache-like reserved space to handle burst I/O in real time, greatly maximizing the advantages of SSD.

Note: The M.2 SSD is optional. As M.2 SSD operations can easily generate excessive heat, it is recommended to install a heatsink (from QNAP or a third-party provider) on the M.2 SSD.


Optimal computing power and 4K video playback with a graphics card

The TS-473 allows for installing a low-power graphics card (powered solely by the PCIe slot) to boost system performance. With a graphics card installed, the TS-473 also enables smoother video editing workflows and supports 4K UHD transcoding to deliver an exceptional multimedia experience. You can also use the QNAP remote control(sold separately) or the Qremote mobile app to use the NAS as a home theater PC.

Note:
1. Supported video formats depend on the hardware and software specifications of the devices. Playback capability and quality may vary due to factors including the original file formats/quality, hardware and software limitations, and output devices.
2. Consult the QNAP Compatibility List before purchasing the graphics card.
3. Graphics card will be supported in QTS 4.3.5 (or later) version.


Use your NAS as a wireless base station

Install a compatible PCIe wireless network card (for example: QNAP QWA-AC2600) on the TS-473 and use with the WirelessAP Station app to use your NAS as a convenient wireless base station. Your mobile devices and PCs can directly connect to your NAS for easy access to its services and Internet connection.


Upgrade your IT environment with QNAP’s fast and affordable 10GbE Switch!

QNAP 10GbE/NBASE-T™ unmanaged switches allow you to instantly upgrade your network environment at a cost-effective price. With a 10GbE network you can enjoy blazing-fast transfer speeds, empower bandwidth-demanding tasks like virtualization, and enable simultaneous real-time access to large NAS-based files using multiple workstations (ideal for video editing and multimedia). QNAP also provide a 10GbE PCIe network expansion card for the TS-473 and Windows®/Linux® PCs to take advantage of high-speed LAN environments.


QTS – The intelligent, intuitive and creative NAS operating system

With modularized multiple applications and functions, QTS enhances management efficiency, personal productivity, multimedia, and much more, making your NAS experience easier, efficient, and more flexible! The built-in App Center with hundreds of install-on-demand apps realizes near-limitless NAS functionality. The new Qboost provides a NAS optimization tool that helps accelerate applications, recover system resources, and schedule applications. QTS breaks the barriers of devices, platforms, and geography to bring you optimized cloud experiences and incorporates advanced features.


The new QVR Pro surveillance solution

QNAP’s new QVR Pro surveillance solution allows you to arrange a dedicated, independent storage space for surveillance data on TS-473 and leverage the advantages of scalability and storage manageability from QTS. With QVR Pro, camera management, storage space allocation, camera live viewing and playback is greatly simplified. You can also use the QVR Pro Client mobile app to monitor your cameras from anywhere, or use a USB webcam as an ONVIF network camera with the QUSBCam2 app.

Note: QVR Pro supports 8 free channels for surveillance monitoring (expandable to 128 channels with additional channel license purchase).


Comprehensive surveillance solution for 24/7 security

The TS-473 provides an intelligent video management system that assists you with real-time monitoring, video & audio recording and playback with a wide range of customizable settings to safeguard your work environment. You can use the Vmobile app to manage monitored channels anytime and anywhere with your mobile devices, or install the Vcam app to turn your mobile device into a network camera to instantly record to your NAS.




Spesifikasi Hardware

CPUAMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor
CPU Architecture64-bit x86
Graphic ProcessorsOptional via a PCIe adapter
Floating Point Unit
Encryption Engine (AES-NI)
Hardware-accelerated TranscodingOptional via a PCIe adapter
System Memory8 GB SODIMM DDR4 (1 x 8 GB)
Maximum Memory64 GB (2 x 32 GB)
Memory Slot2 x SODIMM DDR4
Support ECC memory

For dual-DIMM configurations, you must use a pair of identical DDR4 modules.
Flash Memory5GB (Dual boot OS protection)
Drive Bay4 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable

The following are not hot-swappable: M.2 SSDs, SSD cache drives, SSDs using PCIe expansion slots.
M.2 Slot2 x M.2 2280 PCIe Gen3 x1 slots

The M.2 SSD is not included as standard.
M.2 SSD operations can easily generate excessive heat. It is recommended to install a heatsink (from QNAP or a third-party provider) on the M.2 SSD.
SSD Cache Acceleration Support
GPU pass-through
2.5 Gigabit Ethernet Port (2.5G/1G/100M)2(2.5G/1G/100M)
5 Gigabit Ethernet Port (5G/2.5G/1G/100M)Optional via a PCIe adapter
10 Gigabit Ethernet PortOptional via a PCIe adapter
Wake on LAN (WOL)
Jumbo Frame
PCIe Slot2
Slot 1: PCIe Gen 3 x4
Slot 2: PCIe Gen 3 x4
USB 3.2 Gen 2 (10Gbps) Port3 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
1 x Type-C USB 3.2 Gen 1 5V/1A 5Gbps
HDMI OutputOptional via a PCIe adapter
Form FactorTower
LED IndicatorsStatus/Power, USB, LAN, Drive 1-4, M.2 SSD 1-2
ButtonsPower, Reset, USB Auto Copy
Dimensions (HxWxD)188.2 × 199.3 × 280.8 mm
Weight (Net)5.03 kg
Weight (Gross)6.04 kg
Operating Temperature0 – 40 °C (32°F – 104°F)
Storage Temperature-20 – 70°C (-4°F – 158°F)
Relative Humidity5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit250W, 100-240V AC, 50-60Hz, 3.5A
Power Consumption: HDD Sleep Mode19.576 W
Power Consumption: Operating Mode, Typical29.792 W

Tested with drives fully populated.
FanSystem fan: 1 x 120mm
CPU fan: 1 x 60mm
System WarningBuzzer
Max. Number of Concurrent Connections (CIFS) – with Max. Memory2000
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
