Spesifikasi Hardware
| Part Number | HDWT840UZSVA |
| Basic Specifications | |
| Interface | SATA 6.0 Gbit/s |
| Form Factor11 | 3.5-inch |
| Advanced Format (AF) | Yes |
| Advanced Format (AF) | Yes |
| RoHS Compatible1 | Yes |
| SATA 6.0 Gbit/s | 512e |
| Features | |
| Number of Cameras Supported6 | Up to 64 |
| Drive Bays Supported | Yes |
| Rotational Vibration (RV) Sensors | up To 24 |
| Native Command Queuing (NCQ) | CMR |
| Shock Sensor | yes |
| Tarnish Resistant | yes |
| Toshiba Cache Technology | yes |
| Recording Technology15 | Drive-Managed SMR |
| Perfoemances | |
| Ration Speed | 5,400rpm |
| Buffer size (MB) | 128 |
| Cache Size [MB] | 256 |
| Reliability | |
| 24×7 Operation12 | yes |
| MTTF/MTBF [Hours 10 | 1,000,000 |
| Unrecoverable Error Rate | 1 per 1014 |
| Load/Unload Cycles | 600,000 |
| Limited Warranty [Years] | 3 |
| Power Management | |
| Supply voltage | 5 VDC +5% 12 VDC +10% |
| Consumption (operating) | 4.36 |
| Consumption (active idle) | 2.33 |
| Environmental | |
| Temperature (operating/non-operating) | 0 to 70 (surface) |
| Temperature (Non-operating) [°C | -40 to 70 |
| Vibration (operating) | 4.90 (0.5G} (5 to 350Hz) 2.45 {0.25G} (350 to 500Hz) |
| Vibration (non-operating) | 29.4 (3.0G} (5 to 500Hz) |
| Shock (operating) | 686 {70G} (2 ms duration) |
| Shock (non-operating) | 3,430 (350G} (2 ms duration) |
| Acoustics (idle mode) | 22 dB typ |
| Physical | |
| Dimensions | 147 (L) x 101.85 (W) x 26.1 (H) |
| Weight | 650 g |
