Spesifikasi Hardware
| Part Number | HDWD240UZSVA |
| Basic Specifications | |
| Interface | SATA 6.0 Gbit/s |
| Form Factor11 | 3.5-inch |
| Advanced Format (AF) | Yes |
| Advanced Format (AF) | Yes |
| RoHS Compatible1 | Yes |
| Recording Technology | SMR |
| Features | |
| Ai Streams | No |
| Number Of Camera | up To 64 |
| Dive Bays Supported | up To 24 |
| Recording Technology14 | CMR |
| Toshiba Cache Technology | yes |
| Rotational Vibration Saferguard | yes |
| Shock Sensor | yes |
| Perfoemances | |
| Ration Speed | 5,400rpm |
| Buffer size (MB) | 128 |
| Average latency (ms) | 5.56 |
| Reliability | |
| Limited warranty (years) | 2 |
| Unrecoverable error rate | 1 per 10 |
| Load/Unload cycles | 600,000 |
| Power Management | |
| Supply voltage | 5 V DC ±5 % 12 V DC ±10 % |
| Consumption (operating) | 4.11 W typ |
| Consumption (active idle) | 2.32 W typ |
| Environmental | |
| Temperature (operating/non-operating) | 0 to 60 °C -40 to 65 ° |
| Temperature (Non-operating) [°C | -40 to 70 |
| Vibration (operating) | 4.90 m/s2 {0.50 G} (5 to 350 Hz) 2.45 m/s2 {0.25 G} (350 to 500 Hz) |
| Vibration (non-operating) | 29.4 m/s2 {3.0 G} (5 to 500 Hz) |
| Shock (operating) | 686 m/s2 {70 G} (2 m duration) |
| Shock (non-operating) | 3,430 m/s2 {350 G} (2 msduration |
| Acoustics (idle mode) | 22 dB typ |
| Physical | |
| Dimensions | 147 (L) x 101.85 (W) x 26.1 (H) |
| Weight | 650 g |
