AS1202T

Rated 5 out of 5

Original price was: Rp 4.230.000.Current price is: Rp 3.730.000.
sudah termasuk PPN

Untuk Pemesanan Konfirmasi Terlebih Dahulu

  • Equipped with Realtek RTD1619B 1.7GHz quad-core processor
  • Superfast 2.5-Gigabit Ethernet
  • 1 GB DDR4 RAM
  • Upgraded powerful internal display, smooth transcoding of 4K videos
  • Supports Wake on LAN and Wake on WAN
  • Tool-free installation

Anda dapat membeli di online store

Spesifikasi Hardware



CPU ModelRealtek RTD1619B
CPU ArchitectureARM64 64-bit
CPU FrequencyQuad-Core 1.7GHz
Memory1GB DDR4
Memory Expandable up tonot expandable
Flash Memory8GB eMMC
Drive Bays2
Compatible Drive Type3.5″ SATA HDD
Maximum Drive Bays with Expansion Unit14
Expansion3 x USB 5Gbps Type-A
Network1 x 2.5 Gigabit Ethernet (2.5G/1G/100M)
Multimedia OutputN/A
System Fan1 x 70mm
Power Supply Unit / Adapter65W x1
Input Power Voltage100V to 240V AC
CertificationFCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Warranty3 Years
Power Consumption11.6W (Operation);
5.97W (Disk Hibernation)
Noise Level18.6dB (HDD idle)
Operation TemperatureOperation Temperature
Storage Temperature-20°C~70°C (-4°F~158°F)
Humidity5% to 95% RH
Size165(H) x 102(W) x 218(D) mm
Weight1.14 kg / 2.5 lbs



Software & Features

General Specifications

Supported OS
  • Windows 10, 11, Server 2016, Server 2019, Server 2022
  • macOS
  • UNIX, Linux, and BSD
Supported LanguagesDeutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย
Supported Browsers
  • Firefox
  • Chrome
  • Safari
  • Microsoft Edge

Network

Network ProtocolsCIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Network Protocols
  • TCP/IP (IPv4 & IPv6)
  • Jumbo Frame (MTU)
  • VLAN
  • EZ Connect
  • Wireless Network
  • DDNS and EZ-Router
  • Supports Wake-on-LAN (WOL)
  • Supports Wake-on-WAN (WOW)

File Management & Sharing

File System
  • Internal Disk: EXT4 ,Btrfs
  • External Disk: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT
File Explorer
  • Web-based File Management
  • ISO File Mounting
  • Share Links
  • Task Monitor
  • Browse Files on Local PC
  • Thumbnail Previews
  • Data Access via External Optical Drive
  • Supports video playback
Network Recycle Bin
  • Share folder-based
  • Maintains original directory structure and file permission
  • On-click restore
  • Supports scheduled emptying
  • Filtering rules
    1. File size
    2. File extension
  • Deletion Settings
    1. File size
    2. File date
  •

Storage management

Supported RAID levels
  • Single
  • JBOD
  • RAID 0
  • RAID 1
  •
Supported RAID migration methods
  • Single to RAID 1

Volume

RAID levels supporting storage expansion by complete drive replacement
  • RAID 1
RAID levels supporting storage expansion by drive addition
RAID spare drive support
iSCSI/IP-SAN
  • Maximum Targets: 256
  • Maximum LUNs: 256
  • Maximum Snapshot Versions of a Single LUN: 256
  • Target Masking
  • LUN Mapping
  • ISO File Mounting
  • Supports MPIO
  • Persistent (SCSI-3) Reservations
Disk Management
  • Scheduled Bad Block Scans
  • Scheduled S.M.A.R.T Scans

Backup

Backup Solutions
  • Rsync (Remote Sync) Backup
  • Cloud Backup
  • FTP Backup
  • External Backup
  • EZ Sync
  • SMB Backup
Snapshots
  • Btrfs Snapshots
  • 256 Snapshots
  • iSCSI LUNs
  •

Access & Security

Access Control
  • Maximum Number of Users: 4096
  • Maximum Number of Groups: 512
  • Maximum Number of Shared Folders: 512
  • Maximum Number of Concurrent Connections: 512
  • Supports Windows Active Directory
  • Supports Windows Active Directory / LDAP
ACL
  • Provides both Windows ACL and Linux ACL permission configuration methods
  • Can enable Windows ACL for specific shared folders
  • Comprehensive support for Windows’ 13 types of advanced permission settings
  • Can view Windows ACL permission settings from within ADM
  • Supports local users and groups
  • Exclusive permission reset function allows users to quickly restore default permissions
System Administration
  • Log Type: System Log, Connection Log, File Access Log
  • Real-time Online User Monitor
  • Real-time System Monitor
  • User Quota
  • Virtual Drive (ISO Mounting, Maximum 16)
  • UPS Support
  •
Security
  • AES 256-Bit Encryption
  • Firewall: Prevent Unauthorized Access
  • Alert Notifications: E-mail, SMS
  • Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
  • Built-in Hardware Encryption Engine
Network Defender
  • Auto black list
  • Trusted list
  • Black/White list
    • Supports IP/IP range/geolocation

Others

ASUSTOR Hightlight
  • System Migration
  • EZ Connect
  • Dr. ASUSTOR
  • 2-way Backup
  • Task Monitor
Supported RAID migration methods
  • Auto-Standby for Both Internal and External Disks
  • Auto Fan Control
  • LED Night Mode
  • Power Schedule: On, Off, Restart



Featured Apps



Official ASUSTOR Apps

Antivirus (ClamAV)
  • Scheduled Scans
  • Automatic Virus Definition Updates
  • Quarantine Infected Files
Download Center
  • Supports BT(Torrent & Magnet Link), HTTP and FTP Downloads
  • Torrent Search
  • Choose Files Before a BT Task Starts
  • Customizable Download Schedule
  • Bandwidth Control
  • RSS Subscription and Automatic Downloading (Broadcatching)
  • ASUSTOR Download Assistant for Windows & Mac
  • AiDownload for Android with Push Notification
  • Smart Download Function
Cloud Backup Center
  • Support Amazon S3, Backblaze B2, Microsoft Azure Blob Storage, Alibaba Cloud, Baidu Cloud, IBM Cloud and Rackspace Cloud Files, SFTP, WebDAV, Box, hicloud S3, Google Cloud Storage
  • Immediate or scheduled backup
  • Perform multiple backup tasks and back up multiple accounts
DataSync Center
  • Support OneDrive, OneDrive Business, Google Drive, Dropbox, and Baidu Wangpan,Yandex
  • Supports file filter and bandwidth limitation
  • Supported backup methods:
    • Sync
    • Directly upload files to Cloud from NAS
    • Directly download files from Cloud to NAS
FTP Explorer
  • Directory Structure View with Drag & Drop Transfers
  • Task Monitor
  • Stopping of Transmission Task & Resumption of Connection
  • Encrypted Connections: Explicit over TLS, Implicit over TLS
  • FTP Site Manager
  • Bandwidth Control
  • Maximum Simultaneous Transfer Control
HiDrive
  • Each ADM Account is Able to Individually Log in to One HiDrive Account
  • Supported Backup Methods:
    • Directly Upload Files to HiDrive from NAS
    • Directly Download Files from HiDrive to NAS
  • Supported Protocols:
    • Rsync
    • FTP
    • FTPS
    • SFTP
    • Rsync + SSH
LooksGood
  • Built-in three main video library categories; movies, TV shows, home movies and smart video sorting management
  • Efficient global search function allows for searches by keywords followed by the execution of more detailed searches for the purpose of finding categories of movies, TV shows, home movies and parameters such as actors, director, year, genre, writer and title
  • Attractive poster wall and thumbnail display
  • Automatic production of video poster thumbnails
  • Centralized management and ability to configure order of favorites and playlist history
  • System administrator is able to configure video library and editing permissions according to user preferences
  • Can configure access permissions to share with friends and family
  • Multimedia conversion feature
  • Self-defined smart folder for video conversions
  • Easy Streaming with Chromecast and DLNA
  • Supports playback of videos in Apple TV via AiVideos tvOS version
Mail Server
  • Each ADM Account can Become an Independent Email Account
  • Email Activity Monitor (Over 1 Week, 1/3/6 Months)
  • Provides SMTP, IMAP and POP3 Mail Protocols
  • Supports SMTP Relay and Verification
  • SMTP-SSL Secure Connections
  • Spam Filter and Black List Settings
  • Antivirus Scanning for Emails
  • Email Alias Creation and Mapping
  • Monitoring of Mail Queue
  • Mail Service Activity Log
  • Exclusive Email Backup Mechanism
  • Auto-Forwarding and Auto-Response Protocols
Photo Gallery 3
  • Quickly find and view photos from a specific date in Photo Gallery 3’s timeline.
  • Photo Gallery 3 sorts your photos in a smarter way. Smart albums found in Photo Gallery 3 include places, videos, recently added, favorites and duplicates.
  • Supports two methods to share photos, share links to other NAS users or to friends and family. All shared albums have optional encryption to protect sensitive information.
  • Easily understand photo metadata as well as edit photo descriptions to make photo identification easier.
  • Easily find photos by keyword search.
  •
Surveillance Center
    • Up to 64 channels in 720p on single live view display
    • On-screen camera controls including camera PTZ, manual recordings, take snapshots, configure camera settings and open Maps
    • Up to 4 channels of synchronous and non-synchronous playback with audio
    • Intelligent video analytics including motion detection and foreign object detection
    • Supported Browsers: Microsoft Edge, Firefox, Chrome
    • Event notification supports SMS, E-mail, and mobile push notification
    • Automated event action rules
    • Role-based access control
    • RTSP streaming server (video and audio)
    • AiSecure mobile app for iOS and Android with Push notification
    • ONVIF Profile S, T supported
    • CMS Lite supports connect up to 1024 IP Cameras from 32 NAS
    • Two different camera license packages are offered: single channel and 4 channels.
    • Maximum IP Cam (4 Free Camera Licenses; Additional Licenses to be Purchased)
    • Minimum PC Client Requirements
      • CPU: Intel i5/i7 or above
      • RAM: DDR3 4G or above
      • Operating system Windows 7 and onward
      • Windows browsers: Microsoft Edge, Chrome, Firefox
      • Display resolution: 1280×800 pixels or higher for best user experience
      • Network interface: Gigabit x1
      • Independent graphics card is highly recommend
SoundsGood
  • Import Personal/Public Music Collection
  • Personal/Public Music Collection Permission Control
  • Playlist Editor
  • ID3 Tag Editor
  • Local Speaker Support: USB
  • Supported Audio Formats for Browser: MP3, WAV, Ogg
  • Supported Audio Formats for Transcoding Through Browser: AIFF, Flac
  • Supported Audio Formats for Local Speaker: MP3, WAV, Ogg, AIFF, Flac
  • ASUS DAC Support
Takeasy
  • Download from YouTube, Vimeo, Twitch and More
  • Selectable Video Type and Quality
  • Automatic Downloads with Twitch Subscriptions
  • Preview Downloads in Progress
  • Online Playback
UPnP Media Server
  • Supports PS3 and other Digital Media Player Capable Devices
  • Supports On-The-Fly Transcoding for Most RAW Images and Audio(OGG, FLAC)
  • Supported Image Formats: BMP, GIF, ICO, JPG, PNG, PSD, TIF, RAW Image (3FR, ARW, CR2, CRW, DCR, DNG, ERF, KDC, MEF, MOS, MRW, NEF, NRW, ORF, PEF, RAF, RAW, RW2, SR2, X3F)
  •
VPN Client
  • Supported VPN Protocols: PPTP, OpenVPN, WireGuard VPN (ADM 4.2 Onwards)
  • Transmission Package Monitor
  • PPTP Authentication: PAP, CHAP, MS CHAP, MS CHAP2
  • PPTP Encryption: No MPPE, MPPE (40, 128 bit), Maximum MPPE (128 bit)
  • OpenVPN Port Control
  • OpenVPN Link Compression
VPN Server
  • Supported VPN Protocols: WireGuard VPN, PPTP, OpenVPN, and L2TP/IPsec
  • View Current Connections & Ability to Disconnect Suspicious Connections
  • Comprehensive Connection Log
RADIUS Server
  • Centralized management of wireless network certification
  • Using WPA-Enterprise or WPA2-Enterprise encryption
  • Must be combined with a wireless router that supports RADIUS authentication
SNMP Server
  • Supports SNMP v1, v2c, v3 and trap
  • ASUSTOR NAS MIB provided
Syslog server
  • Supports standard syslog protocol
  • Graphical log monitoring by time and device
  • Supports TCP and UDP
  • Auto log archiving
  • User-defined email notification
  •
