Spesifikasi Hardware
| Basic Information |
| Brand |
CZUR |
| Model |
Lens 1200 Pro |
| Region |
Overseas |
| Product Type |
Smart Scanner |
| Product Series |
CZUR Lens |
| Application scene |
Enterprise, Education, Family, Personal and so on |
| Scanning Material |
Documents, archives, forms, vouchers, ID documents and so on |
| Regular Parameter |
| Sensor |
CMOS |
| Pixel |
12 megapixels |
| Resolution |
4032*3024 |
| DPI (default) |
≈330 |
| Scan Format |
≤A4 |
| Scan Speed |
≤1 sec |
| Pre Scan |
0 sec |
| Image Format |
JPG、TIFF |
| Image Color |
24 bits |
| Static File Output Format |
JPG, PDF, Searchable PDF, Word, Excel |
| Dynamic File Output Format |
MP4 |
| Video Stream Format |
MJPG,Switchable YUV |
| Video Parameter |
MJPG 4032*[email protected] |
| Focus mode |
Fixed focus |
| Optics |
| Lens Structure |
3G2P+IR |
| Light-Sensing Surface |
1/3.2″ |
| EFL |
4.7mm±5% |
| BFL |
6.18mm±5% |
| F/NO. |
3.5 |
| IR Cut |
650±10nm |
| Angle |
62°±5% |
| Distortion |
＜0.5% |
| Configuration Parameter |
| Ports |
Type-c |
| Hall switch Sensor |
√ |
| Power Indicator Light |
White |
| Major Microphone |
Digital MIC |
| Scan Light Source |
Natural light 、 LED fill light |
| LED Fill Light |
Support |
| Top LED adjustment mode |
Smart Control: Turn off the light when crossbar closed and turn on the light when crossbar unfolded automatically;
Key Control: ON, OFF. |
| Side Fill Light |
× |
| Foot Pedal |
× |
| Soft Document Pad |
Support |
| Power |
USB 5V/500mA |
| Power |
USB 5V/500mA |
| Specific Function |
| Document Scanning |
√ |
| Visual Presenter |
√ |
| Major Camera Scene Shooting |
√ |
| Deputy Camera Scene Shooting |
|
| Base Rotation |
√ Rotate 180 degrees horizontally |
| Face recognition |
× |
| OCR Text Recognition |
Support 185 languages |
| TWAIN Port |
x |
| SDK Development Package |
x |
| Video |
1920*1080 and 1600*1200 optional, contains sound |
| Scan Method |
PC software triggering, auto-scan after page turning detection |
| OS |
XP/Win7/Win8/Win10, 32-bit or 64-bit；MacOS |
| Packaging and Accessories |
| Product Color |
Black |
| Product Dimension |
325.5*105*78.5mm |
| Product Weight |
0.42 Kg N.W. 1.05kg G.W. |
| Packaging List |
Scanner, Type-C Cable, Soft Document Pad, CD, Getting Started Guide |
[su_spacer size=”40″]
Computer Configuration Requirements
| OS |
Win XP SP3, 7,8,10 & 11 |
MacOS 10.13 or later
Old version (10.11, 10.12) |
| CPU |
PC with X86 processor (2 GHz or higher) |
| Memory |
4GB RAM minimum, 8GB RAM recommended. |
| Hard Disk |
The installation and operation of the program requires 1 GB disk space. You can scan more images if the disk space is bigger. The recommended storage is 20G. |
