Description
[vc_row][vc_column][vc_column_text]
The QuTS hero NAS TS-h977XU-RP is powered by an AMD Ryzen™ 7 processor that delivers supreme system performance with up to 8 cores/16 threads and Turbo Core up to 4.4 GHz. Running the brand new QuTS hero operating system that incorporates ZFS, the TS-h977XU-RP supports near-limitless snapshots, SnapSync, block-level inline data deduplication, and inline data compression. The TS-h977XU-RP helps your business achieve reliable service-level agreement performance, whether in mission-critical file server, virtualization server, VDI, collaborative video editing, or efficient file backup and recovery applications.
[vc_empty_space height=”50px”]
[vc_empty_space height=”50px”]
Absolute performance with AMD Ryzen™ processor
Powered by a high-performance AMD Ryzen™ 7 3700X 8 cores/16 threads 3.4 GHz processor (Turbo Core 4.4 GHz) with AES-NI encryption acceleration and up to 128 GB DDR4 RAM, the TS-h977XU-RP delivers aggressive yet power-smart performance to meet your multi-tasking demands and is capable of running multiple virtual machines simultaneously. For resource-demanding business applications such as VDI, R&D, private cloud, and server virtualization, the TS-h977XU-RP delivers high performance and dependable reliability for rugged business IT environments as a cost-efficient NAS solution.

Dual-channel memory to deliver power-smart performance
The TS-h977XU-RP supports dual-channel DDR4 memory and four Long-DIMM slots. When using paired memory modules, the TS-h977XU-RP can leverage the power of dual-channel architecture to boost performance. You can also customize the memory configuration (supports up to 128 GB RAM) of the TS-h977XU-RP, making it the most ideal and cost-efficient storage solution for environments including virtualization that contain dynamically-changing workloads.

[vc_empty_space height=”30px”]
[vc_empty_space height=”50px”]
Real-time SnapSync ensures minimal RPO with real-time disaster recovery
Real-time SnapSync ensures that both the primary and secondary NAS maintain identical data. When data is written to the source, it is immediately written to the destination. If the primary NAS goes offline, IT staff can simply adjust the privilege settings of the secondary NAS to ensure continuous operations. SnapSync provides the strongest support for nonstop business operations and helps users to reduce the risk of data loss.
Note: SnapSync will be available from QuTS hero h4.5.2.

[vc_empty_space height=”30px”]
[vc_empty_space height=”50px”]
SPESIFIKASI
TS-h977XU-RP-3700X-32G
- Download Datasheet
- Download Datasheet
- Download Datasheet
CPU | AMD Ryzen™ 7 3700X 8-core/16-thread 3.6 GHz processor, Turbo Core 4.4 GHz |
CPU Architecture | 64-bit x86 |
Encryption Engine | (AES-NI) |
System Memory | 32 GB UDIMM DDR4 (2 x 16GB) |
Maximum Memory | 128 GB (4 x 32 GB) |
Memory Slot | 4 x Long-DIMM DDR4 |
Flash Memory | 5 GB (Dual boot OS protection) |
Drive Bay | 4 x 3.5-inch + 5 x 2.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Hot-swappable | |
SSD Cache Acceleration Support | |
Gigabit Ethernet Port (RJ45) | 2 |
10 Gigabit Ethernet Port | 2 x 10GbE SFP+ SmartNIC port, 2 x 10GBase-T port |
Wake on LAN (WOL) | |
Jumbo Frame | |
PCIe Slot | 1 Slot 1: PCIe Gen 3 x16 PCIe slot is preinstalled with a 10GbE network adapter
|
USB 3.2 Gen 1 port | 4 |
USB 3.2 Gen 2 (10Gbps) Port | 1 x Type-A USB 3.2 Gen 2 10Gbps |
Form Factor | 1U Rackmount |
LED Indicators | HDD 1-9, Status, LAN, storage expansion port status |
Buttons | Power, Reset |
Dimensions (HxWxD) | 43.3 × 482.6 × 505.54 mm |
Weight (Net) | 8.62 kg |
Operating temperature | 0 – 40 °C (32°F – 104°F) |
Storage Temperature | -20 – 70°C (-4°F – 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | 300W(x2), 100-240V |
Power Consumption: Operating Mode, Typical | 76.43 W
Tested with drives fully populated.
|
Fan | System fan: 3 x 40mm, 12VDC |
Sound Level | 43.8 db(A) |
System Warning | Buzzer |
[vc_empty_space height=”30px”]
[vc_empty_space height=”50px”]
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test
Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
